- Single Loop Controller
- Compact Design: 65 mm depth, 5 mm front panel mask.
- Inputs: Supports thermocouples, RTDs, DC current, and voltage.
- Accuracy: ±0.3% FS ±1 digit; ±0.6% FS for negative thermocouple ranges.
- Fast Sampling: 0.3-second response time.
- Outputs: Relay, voltage pulse, current (0–20 mA/4–20 mA).
- Control Modes: ON/OFF, PID, and Heat/Cool control.
- Display: 4-digit LED (green PV, orange SP).
- Communication: RS-485 standard.
- Power Options: 100–240 Vac or 24 Vac/Vdc.
- Lead times for non-stocked items are generally 6-8 weeks. For urgent needs, please get in touch with us to explore additional options.
Introducing the Azbil C26 Series Single Loop Controller is a compact, high-performance digital controller designed to deliver precision and flexibility for process control applications. With advanced algorithms like "RationaLOOP" and "Just-FITTER," this controller ensures optimized performance for industrial systems. It supports various input types, including thermocouples, RTDs, current, and voltage, with easy setup via a PC loader port. Its intuitive interface, high accuracy, and advanced PID tuning options provide exceptional reliability and user convenience.
Specifications:
- Inputs: Multi-range inputs (thermocouple, RTD, DC current, DC voltage).
- Accuracy: ±0.3% FS ±1 digit; ±0.6% FS ±1 digit in negative thermocouple ranges.
- Design: Compact depth of 65 mm with a front panel mask of 5 mm.
- Sampling Time: 0.3 seconds.
- Display: 4-digit LED (green for PV, orange for SP).
-
Outputs:
*Relay contact
*voltage pulse
*current (0-20mA/4-20mA). - Max. load resistance: 600Ω.
-
Control Methods:
*ON/OFF or PID control.
*Heat/Cool control with dual output points. - Communication: RS-485 (3-wire) standard.
- Event Outputs: Up to 3 points for alarms and status indicators.
- Power Supply: 100-240 Vac or optional 24 Vac/24 Vdc.
Upgrade with Azbil C26 Series Single Loop Controller with its compact design, high accuracy, multi-range inputs, and versatile outputs, the Azbil C25/C26 Series is the perfect solution for industries requiring reliable and efficient process control. Its advanced PID tuning, support for Heat/Cool control, and easy configuration via a PC loader make it a valuable addition to manufacturing, HVAC, and automation systems. #SingleLoopController #Azbil #CascadeIndustrial
