- Vertical Explosion-Proof Switch
- Certified by KEMA, NEPSI, KOSHA, and the Technology Institution of Industrial Safety
- Versatile installation with compatible actuator heads
- Mechanical Life: Min. 4 million operations (varies by actuator type)
- Operating Temperature: −10 to +60˚C
- Operating Humidity: 45–85% RH
- 200 m/s² impact resistance, 1.5 mm peak-to-peak amplitude at 10 to 55 Hz
- Out of Stock Models: Estimated Arrival 4 to 6 Weeks
Introducing the Azbil LX7000 Series Vertical Explosion-Proof Switch, engineered for superior performance in hazardous environments, including hydrogen gas atmospheres. Certified by KEMA, NEPSI, KOSHA, and the Technology Institution of Industrial Safety, LX7000 Series ensures safety and reliability. Its lightweight, die-cast aluminum alloy construction with a corrosion-resistant finish makes it ideal for outdoor applications, providing excellent weather resistance. Compatible with a variety of actuator heads, it offers versatile installation options to meet diverse industrial needs.
Specifications:
- Contact Form: 2-circuit double break (2CKT-DB×1)
- Terminal Type: M4 pan head screw with square washer
- Contact Material: Silver/gold-plated rivet
- Electrical Ratings:
- Silver Contacts: 5A at 250 Vac, 0.8A at 125 Vdc, 0.4A at 250 Vdc
- Gold-Plated Contacts: 0.1A at 125 Vac, 0.1A at 30 Vdc
- Dielectric Strength:
- 600 Vac between continuous terminals
- 2000 Vac between terminals and non-live metal parts/ground
- Insulation Resistance: Minimum 100 MΩ (500 Vdc megger)
- Impact and Vibration Resistance: 200 m/s² impact resistance, 1.5 mm peak-to-peak amplitude at 10 to 55 Hz
- Mechanical Life: Min. 4 million operations (varies by actuator type)
- Operating Temperature: −10 to +60˚C
- Operating Humidity: 45–85% RH
- Storage Conditions: −10 to +60˚C, max. 98% RH with conduit section plug inserted
- Electrical life:
- Silver: min. 200,000 operations, 5 A at 250 Vac, 0.8 A at 125 Vdc, 0.4 A at 250 Vdc
- Gold-plated: min. 2 million operations, 0.1 A at 125 Vac, 0.1 A at 30 Vdc
- Hazardous area classification: Zone 1 and Zone 2 hazardous areas
Choose the Azbil LX7000 Series Vertical Explosion-Proof Switch for a reliable, safe, and robust explosion-proof switch that excels in challenging environments. #LX7000 #Azbil #CascadeIndustrial
Note: Out of stock items usually have a lead time of 4-6 weeks. Upon receipt of your order, delivery will be reconfirmed with the factory to ensure accurate timelines.
