ESPP-H1-H-10 | Electronic Pressure Switch

Enhance your hydraulic and pneumatic systems with the Tokyo Keiki ESP Series Electronic Pressure Switch, engineered for accurate pressure detection, reliable switching performance, and long service life. Designed for industrial automation, hydraulic equipment, and OEM machinery, the ESP Series delivers stable pressure monitoring with transistor output, adjustable sensing ranges, and durable construction for demanding environments. Trusted worldwide, Tokyo Keiki is recognized for manufacturing premium hydraulic and fluid control solutions that maximize system efficiency and operational reliability.

Specifications:

• Type: Electronic Pressure Switch
• Mounting Thread: R1/4 or G1/4 (O-ring Seal)
• Pressure Setting Ranges:
• 0.02–1 MPa
• 0.2–10 MPa
• 0.7–35 MPa
• 1–50 MPa
• Power Supply: DC 24V (10–28V)
• Output: NPN Open Collector, DC30V, 80mA Max.
• Contact Options: 1 or 2 contacts (fixed or variable deadband)
• Pressure Setting: Rotary variable resistor (3-turn adjustment)
• Operating Temperature: -20°C to +70°C
• Humidity Range: 5–90% RH
• Protection: Drip-proof or Water-proof models
• Cycle Durability: Over 10 million operations
• High vibration and shock resistance for industrial environments

Choose the Tokyo Keiki ESP Series for dependable pressure control, exceptional durability, and consistent performance in demanding industrial applications.
