- Pressure: Up to 14 MPa (7 MPa for FA, FB, LB models).
- Stroke: Up to 2000 mm.
- Speed: 8 to 400 mm/sec.
- Temperature: -5° to +80°
- Threads: JIS pipe taper thread.
- Lead times for non-stocked items are generally 18-20 weeks. For urgent needs, please contact us to explore additional options.
Available:
In stock
In stock
In stock
Out of stock
Pre Order
Back in stock
$0.00
Maximize industrial uptime and operational precision with the Tokyo Keiki TJ Series Standard Hydraulic Cylinder. Engineered by Tokyo Keiki, a global leader in high-performance fluid power solutions, the TJ Series delivers exceptional reliability, smooth actuation, and long-term durability.
They are the ultimate choice for machine tools and general manufacturing sectors requiring precise linear motion. With multiple support unit models and custom seal configurations, Tokyo Keiki provides versatile options tailored to your heavy-duty systems.
Key Specifications
- Working Pressure: Up to 14 MPa (7 MPa limit applies to FA, FB, and LB support unit models).
- Bore Sizes: Broad selection from $\phi 30\text{ mm}$ up to $\phi 250\text{ mm}$.
- Maximum Stroke: Dynamic configurations accommodating up to 2000 mm.
- Cylinder Speed: Operating velocity range between 8 mm/sec and 400 mm/sec.
- Ambient Temperature Range: Fully operational from $-5^\circ\text{C}$ to $+80^\circ\text{C}$.
- Pipe Connection: Features a standard JIS pipe taper thread system.
- Gasket & Seal Options: Highly resilient material variants including Nitrile rubber, Urethane rubber, Fluororubber, PTFE, and Metal.
Upgrade your manufacturing machinery with the trusted engineering of Tokyo Keiki TJ Series.
