Tokyo Keiki Products
- Reduced power consumption
- Direct connection to PLCs
- Wide range of compatible hydraulic fluids
- Low-holding current operation for extended valve life
- Standard or left-hand build for flexibility
- Plug-in solenoids for easy installation
- Sink or source contact point input for compatibility with different control systems.
Introducing the DG4V-3 Series Directional Control Valve from Tokyo Keiki
- Wet type solenoid valve with low switching noise and superior valve life, no leakage worries
- Multiple valve options with various wiring connections, indicator lamp, surge suppressor, and AC/DC rectifier
- Compatible with standard mineral oil and water-glycol based fluids. Models beginning "F3" are also compatible with phosphate ester.
- Solenoid operated directional control valve with wet armature type.
- ISO 4401-03 mounting dimensions
- Electrical wiring options: plug-in solenoids, DIN43650 connectors, or flying leads (standard lead wire length: 350 mm, DC 12 V, 24 V only)
Introducing the DG4M4 Series Directional Valve, Tokyo Keiki
- Compact solenoid directional valve suitable for up to 21 MPa.
- Features resin molded dual frequency coils (50/60 Hz) with two terminals, eliminating the need for coil rewiring.
- Designed for use with standard hydraulic fluids, including mineral oil-based, water glycol-based, and phosphate ester.
- Miniature size with a wet armature type for efficient operation.
20%
- Hydraulic Fluid: Mineral Oil / Water Glycol (Standard), Phosphate Ester (F3)
- Pilot Operated Check Valves
- ISO 4401-03 Mounting Dimensions
- Decompression Function: D variant
- Control Line: AB or BA
- Cracking Pressure: K (0.1 MPa), M (0.25 MPa), N (0.5 MPa)
- Poppet valves control one-way flow in hydraulic systems.
- Cartridge valves enhance design for bidirectional flow control.
- Manifold blocks reduce leakage in hydraulic systems.
- Offers high flows and efficiency.
- Advantages: design flexibility, lower cost, improved reliability.
- Considerations: high flow rates, pressure, compact size.
- Cartridge valves optimize system performance with easy customization.
- Hydraulic Fluid: Mineral Oil / Water Glycol (Standard), Phosphate Ester (F3)
- Mounting: ISO 4401-05 dimensions
- Control Ports: P, A, and B lines
- Multiple Adjustable Pressure Ranges to choose from.
- Drain: External option available
- Piping connection: G1/8 Gauge port
- High-performance, reliable hydraulic pressure reducing valve for optimized system efficiency.
20%
- Choose between standard hydraulic fluid (Mineral Oil) or Water Glycol (F11)
- Mounting bracket (F) is available for mounting flexibility & stability
- Maximum Displacement: 70cm³/rev (33.3 GPM)
- Maximum Operating Pressure: 21MPa (3,050psi)
- Speed Range: 600-1800 (rpm)
- Rotation: Right-hand (R) & Left-Hand (L) Rotations available for flexibility
- Max Displacement Customization
20%
Introducing the DG4V-3 Series Directional Control Valve from Tokyo Keiki
- Wet type solenoid valve with low switching noise and superior valve life, no leakage worries
- Multiple valve options with various wiring connections, indicator lamp, surge suppressor, and AC/DC rectifier
- Compatible with standard mineral oil and water-glycol based fluids. Models beginning "F3" are also compatible with phosphate ester.
- Solenoid operated directional control valve with wet armature type.
- ISO 4401-03 mounting dimensions
- Electrical wiring options: plug-in solenoids, DIN43650 connectors, or flying leads (standard lead wire length: 350 mm, DC 12 V, 24 V only)
TOKYO KEIKI
EPFRCG-06-175-500-EX-10-TN-S7B - Direct Operated Proportional Solenoid Relief Valve - EPFRCG Series -48287073
20%
TOKYO KEIKI
EPFRCG-06-175-500-EX-10-TN-S7B - Direct Operated Proportional Solenoid Relief Valve - EPFRCG Series -48287073
- Utilizes a proportional solenoid actuator to provide proportional control of hydraulic circuit pressure.
- The valve provides pressure control proportional to input current by connecting with small flow hydraulic systems, pilot operated pressure control valves or variable displacement pumps.
20%
- Proportional Solenoid Relief Valve
- Max Working Pressure: 21MPa
- Flow Range: 0.3-1.5L/min
- Rated Current: 1A
- Coil Resistance: 14Ω
- Hysteresis: <3%
- Repeatability: <1%
